HUB (KX-HNB600) | Colour | White |
Frequency range | DECT: 1.88 GHz - 1.90 GHz Wi-Fi: 2.412 GHz – 2.472 GHz |
Wireless Network Standard | Wi-Fi: IEEE 802.11 b / g / n |
Encryption | WPA2-PSK (TKIP / AES), WPA-PSK (TKIP / AES), WEP (128 / 64 bit) |
SD Card Slot for Recording Video | Yes (microSD Max2GB / microSDHC Max32GB) |
Status Indication | LED (Red / Yellow / Green) |
Alert Tone Volume | 6setp+OFF |
Wall Mountable | Yes |
Operating Conditions | 0°C–40°C 20%–80% relative air humidity (dry) |
Setup Button | One Push Pairing Button (Handset, Camera, Other Device) | Yes |
Wi-Fi Setup Button | Yes |
Maximum Number of Devices | Digital Cordless Handset (KX-HNH100) | Up to 6 handsets |
Camera (KX-HNC600 / HNC200) | Up to 4 cameras |
Sensor / Indoor Siren / Smart Plug (KX-HNS101 / HNS102 / HNS105 / HNA101) | Up to 50 devices |
Smartphone / Tablet | Up to 8 devices * 8 mobile devices can be registered to the Hub, however, only the first 4 can use phone features |
Phone Feature | Landline Telephone Function | Yes |
Smartphone Connect | Yes |
Answering System | Yes |
Call Block | Yes |
Recording Time | For Indoor/Outdoor camera (* Indoor/outdoor camera is required.) | 2 GB card: 15 hours 4 GB card: 30 hours 8 GB card: 60 hours 16 GB card: 120 hours 32 GB card: 240 hours *For live recording and recording by Smart Control feature. *All times are approximate. *Maximum continuous recording time is 15 minutes. |
Sensor Detect Notification (Window Sensor / Motion Sensor / Motion Sensor in Camera) | Via Landline Call | Yes |
Via Home Network System Application | Yes |
HUB Buzzer | Yes |
Digital Cordless Handset (Buzzer / Announcement) | Yes / Yes *Requires optional Digital Cordless Handset. |
Power Consumption | Standby | Approx. 4.0 W |
Maximum | Approx. 4.5 W |
Dimensions/ Weight | Dimensions (H x W x D) | Approx. 42 mm x 130 mm x 130 mm |
Weight | Approx. 220 g |
Window/Door Sensor (KX-HNS101) | Colour | White |
Frequency Range | DECT: 1.88 GHz - 1.90 GHz |
Status Indication | LED (Red/Green) |
Setup Button | One Push Pairing button |
Power Source | Lithium battery CR2 (1 x 3.0V, 850mAh) |
Battery Life | UP to 2 years * When window/door is opened and closed 10 times a day in an environment of 25°C and when using a 3.0V, 850mAh battery. The battery life differs depending on the capacity of the battery used. |
Operating Conditions | -10 °C – 40 °C |
Dimensions/ Weight | Sensor Unit Dimensions (H x W x D) | Approx. 102 mm x 31 mm x 22 mm |
Magnet Unit Dimensions (H x W x D) | Approx. 37 mm x 14 mm x 14 mm |
Sensor Unit Weight | Approx. 39 g |
Magnet Unit Weight | Approx. 8 g |
Motion Sensor (KX-HNS102) | Colour | White |
Frequency Range | DECT: 1.88 GHz - 1.90 GHz |
Sensor Detection Method | Pyroelectric infrared sensor (heat sensor) |
Heat Sensor Detection Range | Horizontal: approx. ±45° Vertical: approx. ±10° Distance: approx. 5 m * * When the surrounding temperature is approx. 25 °C. |
Sensor Sensitivity Select Switch | Yes (High / Low) |
Status Indication | LED (Red/Green) |
Setup Button | One Push Pairing button |
Power Source | AA (LR6) Alkaline battery (2 x 1.5V) |
Battery Life | Up to 1 year * When motion is detected 50 times a day and the surrounding temperature is approx. 25°C. |
Wall Mount | Yes |
Operating Conditions | 0 °C – 40 °C |
Dimensions/ Weight | Dimensions (H x W x D) | Approx. 72 mm x 73 mm x 39 mm *1 Approx. 72 mm x 73 mm x 61 mm *2 *1 With the rear cover attached. *2 With the wall mounting adaptor attached. |
Weight | Approx. 70 g *1 Approx. 77 g *2 *1 With the rear cover attached. *2 With the wall mounting adaptor attached. |
Indoor Siren (KX-HNS105) | Colour | White |
Frequency Range | DECT: 1.88 GHz - 1.90 GHz |
Flash Warning Light | Yes |
Loud sound | Yes |
Sound Volume Switch | Yes (High/Low) |
Status Indication | LED (Red/Green) |
Setup Button | One Push Pairing button |
Power Source | 220 - 240 V AC, 50/60 Hz |
Wall Mount | Yes |
Operating Conditions | 0 °C – 40 °C |
Power Consumption | Standby | Approx. 2.0 W |
Maximum | Approx. 3.0 W |
Dimensions/ Weight | Dimensions (H x W x D) | Approx. 71 mm x 73 mm x 46 mm |
Weight | Approx. 90 g |
